Brand AMPROBE
AC Response Calculation TRMS
Instrument Safety Rating CAT III 1000V; CAT IV 600V
Calibration Certificate Included No
Maximum AC Voltage Measurement 1,000 V
Maximum DC Voltage Measurement 1,000 V
Display Type Backlit LCD
Instrument Counts 6,000
Maximum AC Current Measurement 10 A
Maximum DC Current Measurement 10 A
Multimeter Style Full Size
Parameters Measured
AC Voltage
DC Voltage
AC Current
DC Current
Capacitance
Frequency
Resistance
Temperature (K)
Data Logging Yes
Bluetooth Compatible Yes
Dustproof No
IP Rating IP56
Intrinsically Safe No
Removable Screen No
Thermal Imaging No
Waterproof No
AC Current Measurement Resolution 600 µA
AC Voltage Measurement Resolution 6 V
Capacitance Measurement Resolution 60 nF
DC Current Measurement Resolution 600 µA
DC Voltage Measurement Resolution 600 V
Frequency Measurement Resolution 60 Hz
Basic AC Current Accuracy ±(1.2% Rdg + 5 LSD)
Basic AC Voltage Accuracy ±(1.0% Rdg + 3 LSD)
Basic DC Current Accuracy ±(1.0% Rdg + 2 LSD)
Basic DC Voltage Accuracy ±0.50% + 2 Digits
Capacitance Measurement Accuracy ±(3.0% Rdg + 5 LSD)
Frequency Measurement Accuracy ±(0.1% Rdg + 3 LSD)
Resistance Measurement Accuracy ±1%
Includes
(1) 9V (6F22) Battery Installed
(2) Type K Probe
Carrying Case
Temperature Adapter
Test Leads
Velcro Strap
Manufacturer Part Number AM-570
Audible Continuity Yes
Data Hold Yes
Maximum Resistance Measurement 60 megaohm
Diode Test Yes
Auto Power Off Yes
Auto Ranging Yes
Bar Graph Included Yes
Battery Access Yes
Battery Size 9V
Minimum/Maximum Memory Yes
Computer Interface Connection Type None
Weight 0.78 lb
Maximum Storage Temperature 122 °F
Minimum Storage Temperature 14 °F
Maximum Operating Temperature 104 °F
Minimum Operating Temperature 32 °F
Duty Cycle Yes
Maximum Capacitance Measurement 60 mF
Maximum Frequency Measurement 60 MHz
Maximum Temperature Measurement 1,832 °F
Minimum Temperature Measurement -40 °F
Peak Hold Yes
Depth 7.2 in
Overall Height 1.8 in
Overall Width 3.5 in
Fuse Access Yes
Minimum Resistance Measurement 600 ohm
Minimum Frequency Measurement 60 Hz
Minimum Capacitance Measurement 60 nF
Batteries Included Yes
Multiple On-Screen Displays Yes
UNSPSC 41113630
Country of Origin China (subject to change)

Bluetooth-compatible multimeters use wireless technology to record and transfer data to a PC, smartphone, or similar device. They allow operators to monitor and analyze information remotely and easily share test results in real time.
